Within the UK healthcare system, the development of management of pressure ulcers (PUs) has changed from a basic nursing responsibility toward a more complex clinical activity. With the billions the NHS spends every year on avoidable pressure injuries, clinically justified procurement of support surfaces, based on cost, is unacceptable.
With a mattress selection based on uniformity, patient outcomes are likely to be deficient, and care providers may face higher litigation exposure. For Tissue Viability Nurses (TVNs), Occupational Therapists (OTs), and NHS procurement leads, the goal is to find a match between the biomechanical needs of the patient’s skin (according to EPUAP grading) and the biomechanical matched specific configurations of the reactive and active support surfaces.
Categorizing Pressure Ulcers: Beyond Visual Assessment
Effective selection of tools for clinical use requires knowledge of tools functioning at the tissue level rather than simple surface level observations to identify potential cellular damage.
Category I & II: The Threshold of Tissue Integrity
Compromised micro-vasculature occurs at skin level for Category I (Non-blanchable erythema). Skin hyper-sensitivity to Shear Force occurs here. Internal sloughing may occur when the epidermis has not broken and the bone and deep fascia produce internal friction.
Em Category II pressure ulcer (partial-thickness loss which may be a blister and shallow ulcer), the clinical goal shifts to tissue protection and microclimate control. Moisture at this stage can convert a Category II ulcer to a more complicated ulcer.
Category III & IV: Navigating Deep Tissue Destruction
Once damage falls under Category III (Full-thickness loss) and Category IV (Exposure of bone/tendon), the clinical emphasis is on Total Offloading. At this stage, the internal pressure at the bone-to-muscle interface usually surpasses the capillary closing pressure (approximately 32 mmHg). Wound bed is ischemic, and the absence of a mechanical means to create intermittent “zero pressure” periods, is a primary factor contributing to the incomplete closure of the wound, prolonging the proliferative phase of healing and increasing the likelihood of a systemic septic condition.
The Decision-Making Framework: From Static to Active Surfaces
High-Specification Reactive Foam (Static)
High Specification Foam is a NHS compliant standard. In contrast with generic grade foam clinical surfaces use Castellated Foam. This type of foam is designed to melt and flow in response to body heat and allows the foam to fully adapt to body contours. This is a design feature meant to provide enhanced surface area contact with the patient thereby decreasing the Interface Pressure. These surfaces are satisfactory for patients with high Waterlow Scores and intact skin.
Dynamic Alternating Pressure Systems (Active)
Active systems are necessary for the management of Category III and IV ulcers. These systems inflate and deflate. The clinical process responsible for the healing is the Reperfusion Therapy. In clinical practice, pressure is periodically removed from a body part to achieve blood flow restoration to the capillaries that provide flow to the wound and remove used and non-functional blood components from the area.
Hybrid Technology: Bridging the Gap in Community Care
The Hybrid model which consists of foam cores combined with alternating air cells is leading the way in UK Care Homes. These systems are designed to provide a step up and step down quality, providing the necessary foam for patient dignity and sleep and during high risk periods the mechanical relief of an active system.
Technical Specification Comparison Matrix
| Category | Clinical Presentation | Therapeutic Goal | Recommended Technology | Key Technical Features |
| Category I | Non-blanchable erythema | Prevention & Protection | High-Spec Foam | Vapor permeable, multi-stretch covers |
| Category II | Shallow ulcer, no slough | Friction/Shear Reduction | Static Air or Overlay | Low-profile air cells, zoned support |
| Category III | Full-thickness loss, visible fat | Redistribuição da pressão | Active Alternating | Cell-on-Cell design, Audible alarms |
| Category IV | Exposed bone or tendon | Maximum Offloading | Advanced Dynamic System | Low Air Loss (LAL), Quick CPR release |
Advanced Clinical Considerations for UK Facilities
Microclimate Management (MCM) and Moisture Lesions
Moisture Vapor Transmission Rate (MVTR) is an essential value for the mattress cover. Patients with Category II+ ulcers experience an increase in skin temperature and perspiration, causing the skin to become less resistant. A mattress with high MVTR helps keep the microclimate of the skin dry. This will help prevent the skin from becoming soggy (maceration) which is one of the top factors for the worsening of wounds in the geriatric population.
Safety, Stability, and the “Bottoming Out” Risk
“Bottoming out”, a situation where a patient goes through the air cells and drops down to the bed frame, is considered a significant clinical defect. Advanced dynamic systems try to overcome this via what is called Cell-on-Cell technology. This means there is a secondary, permanently inflated lower layer which functions as a safety “cushion” during power outages or when the patient is in the sitting (fowler) position.
Infection Control and Flame Retardancy (Crib 5/7)
All care environments need to adhere to the UK fire safety regulations (Crib 5/7). Moreover, from the infection control standpoint, Stitched seams cannot compete with High-frequency Welded Seams. The reason being, they stop fluid from penetrating the foam core which is critical to avoid cross-contamination and prolong the usable life of the item.
High-Level Clinical FAQ
Q1: Can we justify the use of static foam for Category III if patient mobility is high?
Answer: If the patient has an ulcer that is localized and of Category III level (ex: involves a medical device / trauma incident investigation that is short term) then the patient foam should be used. If the mobility is only for bed shift then an active system is needed to ensure that that level of rest is actively achieved.
Q2: What is the optimal cycle time for Category IV ulcers on a dynamic system?
Answer: Clinical studies show that a cycle time of 10 -12 is an optimal time and has the best benefits. While shorter cycle times can be too aggressive on the skin and longer (20-minutes or more) can leave tissues left ischemic for too long and can slow the healing process of tissues that have deep damages.
Q3: How to prevent ‘Bottoming Out’ in bariatric patients with Grade III ulcers?
Answer: Bariatric care is challenging and requires use of a system with a high Safe Working Load (SWL), and may even require use of a pressure adjusting system that uses integrated pressure sensors to change the pressure of the cells to be above the weight and BMI of the patient so that they can maintain a state of buoyancy within the air cells.
Q4: Is there a role for ‘Turn-only’ protocols when using advanced active surfaces?
Answer: Active surfaces do not replace manual repositioning, but do replace dynamic mattresses. “30-degree tilts” or regular turning protocols are still required to mitigate lateral shear and to assess the condition of the skin, but are performed with decreased frequency based on the equipment’s capabilities.
Conclusion: Enhancing Patient Outcomes through Precise Procurement
Rapidly proceeding through Category I to Category IV entails an increasingly higher degree of clinical risk. The only way to address this is through the provision of more advanced technology in relation to the risk involved—particularly moving from passive to active foam systems. For healthcare providers in the UK, clinical grading systems based procurement of foam mattresses in conjunction with the risk factors involved, optimally allocates resources to protect from the development of pressure injuries and support recovery.
